4060 ruida laser engraving machine

Short Description:

1. Adjustable Speed and Power, Smooth and Precise Engr- aving and Cutting.

2. USB Interface, U-flash Disk Supported, Ethernet cable, WIFI (Optional parts).

3. Air Assist, Remove heat and combustible gases from the cutting surface.

4. Embedded Exhaust Fan, Easier install, Safer transport.

5. Rotary Axis, Engrave any cylindrical object ( Optional p- arts ).

6. Aluminum Knife Worktable or Honeycomb Worktable.

7. Intuitive Control Panel, Set Speed, power and more co- ntrols directly from the laser.

8. Water Cooling and Protection System

9. Red light positioning

10. Emergency Stop Button.

11. Larger Size, 400′ 600mm working area.

12. The lifting platform is electric control.

13. Drag-and-chain transmission line.

14. Laser focal length : 5CM

Send email to us Download as PDF

Product Detail

Product Tags

Application

Application Materials
Acrylic, Plexiglas, double color board, ABS board, PVC board, bamboo, MDF, wood,paper ,leather,fabric, wool,rubber, resin etc.

Application Industry
Advertisement, Garments sampling, Small width tailoring, leath- er industry, shoemaking, decoration, furniture, packing and pri- nting, model industry, craftwork and gift, etc.

LASER HEAD

The air pipe has been installed on it. So that dust will not contact the lens. The blown air can cool the lens and cool the material surface. Red light positioning function ( Optional )

Cooling and blowing

Cool and blow air to prevent cuts from burning. Air Assist Remove heat and combustible gases from the cutting surface

Aluminum knife worktable (Optional)

To process hard materials like acrylic, wood and so on

Honeycomb worktable

1. Small holes make sure good supporting performance which is suitable for leather cloth and other thin oft materials

2. The hole of honeycomb worktable is small , so the small work piece can be placed on the table surface to be processed

Electric Up down worktable

The height of the platform can be adjusted, freely to facilitate products of any thickness

Features

1. Adopt advanced laser engraving and cutting control system : Ruida RDC6442control system, the control pannal support different language include Chinese, English, French, Pyccko, Portuguese, Tukish, German, Spanish, Vietnamese, Korean, Italian

2. Standard Rdworksv8 software : It support 15 different languages, clude : Chinese, English, Japanese, French, German, Portuguese, Polish, Spanish, Russian, Korean, Vietnamese, Indonesian, Italian, Turkrish, Arabic

It can compatible with many other software, like Coreldraw, Photoshop,AUTOCAD, TAJIMA, etc.

You can use these software to make designs, then import to Rdworks to cut or engrave

3. Rdworks software support files in different format : Al, DXF, PLT, DST, B -MP, DSB, EPS, DAT, NC, RDB, GIF, JPG, JPEG, JPE, JFIF, PNG, MNG, ICOCUR, TIF, TIFF, TGA, PCX, WBMP, WMF, EMF, JBG, J2C, JPC, PGX, RASPNM . PGM. RAW

4. Storage : The main board has EMS Memory which enables the user to store more than 100 files

5. Laser output control : Can regulate the laser power from 1-100% according to different material .

6. Interface : USB2 . 0 interface support connect to computer by USB cable, it also support offline work.

LASER TUBE

Closed Co2 laser tube, long life stable power Installation of reinforcement settings, the lase tube is not easy to collide and cause damage when moving the machine ( EFR, RECI, CDWJYONGLI, JOY. Optional)

X Axis can upgrade to linear guide

Special linear guide rail good stability and long service life low noise and high precision

Stepper motor

Strong power, reliable performance. safe and fast. ensure the normal operation of the machine

High Speed Stepper Subd- ivision Driver Control System

Adopt Chinese Top Brand Step Motor and Driving System Num- eral timing Simulation quantum control laser power. Little error, repetition high precision.

Reflector

45 mirror adjustment set. Three-point dimming bolt for easier dimming.

USA II-VI LENS

Imported USA II-VI Lens, suitable for various environments, and has high precision and high speed.

FAMOUS BRANID BELT

The ONK brand belt, wear resistance, good stability, compact structure and low noise

Limit switch

Prevent hitting of moving system

LEADING CHAIN

Towline routing and wear-resistant high-strength cables, beautiful and extend the life of the machine

Buit-in exhaust fan

Built-in Exhaust Fan. Easier install,Safer transport

Security protection

Ensure the safe operation of the machine and the safe use of electricity

Double stop switch

Ensure the safe operation of the machine and the safe use of electricity

LED Light

Easy to use, humanized operation

Product Video

Specification

Technical Parameters

Model	FST 6040 laser engraving cutting machine
Working area	600*400mm
Laser type	sealed co2 glass laser tube
Laser power	40W/50W/60W/80W/100W
Engraving speed	0-30000mm/min
Cutting speed	0-3600mm/min
Cutting thickness	0-20mm ( depends on materials)
Resolution rate	±0.05mm
Data transfer interface	USB2.0
Working voltage	220v±10% 50hz 110v±10%60hz
Min shaping character	character:22mm letter:11mm
Software	RdworksV8/ CorelDraw/AutoCAD
Supported graphic formats	BMP PCX TGA TIF PLT CDR
Working temperature	0-45°C
Working humidity	5%-90%
Rsolution ratio	<4500DPI
Optional parts	Rotary axis,water chiller 3000/5000/5200.
Machine size	≥60W 1400740580mm
Machine size	40W/50W 1030x740x580mm
Package	Packing in export wooden cases
